Product Characteristics
Made from continuously cast copper-clad steel grounding rods, with a hot-dip tin-plated surface, eliminating electrochemical corrosion and the original battery effect, and not affecting cathodic protection.
Tin layer thickness ≥ 30 mm, copper layer thickness ≥ 0.8 mm.
1. Standard grounding electrode (rod) has one flat and one pointed end, with standard lengths of 2.5m and 3m. The lower end is pointed, and the upper end is normally flat. An "end cap" can be fitted to the upper end of the rod for driving it into the ground.
2. Combined grounding electrode (rod) has threads at both ends, connected by a connecting pipe in the middle. It is equipped with a moving head at the upper end and a pointed end at the lower end. Lengths include 1.2m and 1.5m, and can be extended arbitrarily according to different geological conditions and construction environments. Note: The "driving head", "connecting tube", and "tip" of the combined grounding electrode (rod) must be used together and are supplied separately as accessories.
B - Standard Type
Z - Combination Type
(Customizable according to user needs)
Technical Parameters
| Specifications | Diameter (mm) | Length (mm) | Copper Layer Thickness
(mm) |
Tin layer thickness (μm) |
| Standard type | ||||
| XCL-JDB-φ14×2.5-B0.8 | 14 | 2.5 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 16 | 2.5 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 18 | 2.5 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 20 | 2.5 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 25 | 2.5 | 0.8 | 30 |
| Combined type | ||||
| XCL-JDB-φ14×2.5-B0.8 | 14.2 | 1.5 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 14.2 | 1.2 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 17.2 | 1.2 | 0.8 | 30 |
| XCL-JDB-φ14×2.5-B0.8 | 17.2 | 1.5 | 0.8 | 30 |
