XCL High-Precision Series Pure Copper Products
XCL High-Precision pure copper products are made from high-purity electrolytic copper (copper content greater than 99.99%), with a fine molecular structure, extremely low oxygen content, and extremely low electrical resistance. They are free of pores, sand holes, and looseness, and have excellent electrical conductivity, thermal conductivity, corrosion resistance, and machinability. This series of products can be upgraded to tin-plated copper products depending on the project requirements; copper round wire and copper stranded wire products can be fitted with PVC outer sheaths, offering flexible applicability.
Copper Busbar
| Model | Specifications (mm) | Reference Weight (kg/m) Supply | Delivery Length |
| XCL-TP203 | 20×3 | 0.53 | 6 meters/piece |
| XCL-TP254 | 25×4 | 0.89 | |
| XCL-TP303 | 30×3 | 0.8 | |
| XCL-TP404 | 40×4 | 1.42 | |
| XCL-TP505 | 50×5 | 2.23 | |
| XCL-TP606 | 60×6 | 3.2 | |
| XCL-TP808 | 80×8 | 5.7 | |
| XCL-TP10010 | 100×10 | 8.9 | |
| KCL-TP12012 | 120×12 | 12.82 |
Multi-strand bare copper wire
| Model | Cross-sectional area (mm²) | Quantity/Single strand diameter (mm) | Reference weight |
| XCL-TX16 | 16 | 7/1.70 | 0.14 |
| XCL-TX25 | 25 | 7/2.14 | 0.22 |
| XCL-TX35 | 35 | 7/2.52 | 0.31 |
| XCL-TX50 | 50 | 19/1.78 | 0.44 |
| XCL-TX70 | 70 | 19/2.14 | 0.6 |
| XCL-TX95 | 95 | 19/2.52 | 0.83 |
| XCL-TX120 | 120 | 37/2.03 | 1.04 |
| XCL-TX150 | 150 | 37/2.25 | 1.36 |
| XCL-TX185 | 185 | 37/2.52 | 1.62 |
| XCL-TX240 | 240 | 61/2.25 | 2.03 |
| XCL-TX300 | 300 | 61/2.52 | 2.64 |
| XCL-TX400 | 400 | 61/2.85 | 3.53 |
PVC Multi-Strand Pure Copper Stranded Wire
| Model | Cross-sectional Area (mm²) | Quantity/Single Strand Diameter (mm) | Reference Weight |
| XCL-PVC16 | 16 | 7/1.70 | 0.25 |
| XCL-PVC25 | 25 | 7/2.14 | 0.3 |
| XCL-PVC35 | 35 | 7/2.52 | 0.36 |
| XCL-PVC50 | 50 | 19/1.78 | 0.49 |
| XCL-PVC70 | 70 | 19/2.14 | 0.67 |
| XCL-PVC95 | 95 | 19/2.52 | 0.9 |
| XCL-PVC120 | 120 | 37/2.03 | 1.12 |
| XCL-PVC150 | 150 | 37/2.25 | 1.4 |
| XCL-PVC185 | 185 | 37/2.52 | 1.7 |
| XCL-PVC240 | 240 | 61/2.25 | 2.2 |
| XCL-PVC300 | 300 | 61/2.52 | 2.71 |
| XCL-PVC400 | 400 | 61/2.85 | 3.55 |
