Product Characteristics
Utilizing continuously cast copper-clad steel flat wire as the conductor, with a hot-dip tin coating, it exhibits no electrochemical corrosion or galvanic cell effect. It meets relevant standards, with a tin layer thickness ≥30 μm and a copper layer thickness ≥0.35 mm.
(Customization is available to meet various user needs.) Single-strand soft round wire (≥100 meters/coil or 1000 meters/reel).
Technical Parameters
| Specifications | Structural Dimensions Number of 1 Outer Diameter (mm) | Copper Layer Thickness (mm) | Tin Layer Thickness (μm) | Cross-sectional Area (mm²) |
| XCL-BX-12×6BX | 1/12×6 | 0.35 | 30 | 70 |
| XCL-BX-15×8BX | 1/15×8 | 0.35 | 30 | 120 |
| XCL-BX-20×6BX | 1/20×6 | 0.35 | 30 | 120 |
| XCL-BX-22×7BX | 1/22×7 | 0.35 | 30 | 150 |
| XCL-BX-20×8BX | 1/20×8 | 0.35 | 30 | 160 |
| XCL-BX-25×10BX | 1/25×10 | 0.35 | 30 | 250 |
| XCL-BX-25×8BX | 1/25×8 | 0.35 | 30 | 200 |
| XCL-BX-30×10BX | 1/30×10 | 0.35 | 30 | 300 |
